Effective Sensor Size – 17.78mm x 10mm (Four Thirds)
Lens Mount – Active MFT Mount.
Lens Control – Iris, focus, zoom on supported lenses.
Dynamic Range – 13 Stops.
Dual Native ISO – 0dB and 18dB gain.
Sensitivity at 0dB Gain – f11 with 2160p59.94., f12 with 2160p50., at 2,000 lux with 89.9% reflectance.
Signal to Noise Ratio – 63dB for 2160p.
Shooting Resolutions – 3840 x 2160 (Ultra HD) up to 60 fps.
Frame Rates – 23.98, 24, 25, 29.97, 30, 50, 59.94 and 60 frames per second.
Off-speed frame rates up to 60 fps in Ultra HD.
Focus – Auto focus available using compatible lenses.
Metadata Support – Automatically populated lens data from electronic Micro Four Thirds lenses. Automatic recording of camera settings, motion sensor data plus slate data such as project, scene number, take and special notes. A 3D LUT can also be embedded in metadata of Blackmagic RAW files.
Mounting Options – 1 x 1/4 inch (top), 3 x 1/4 inch (bottom)
SDI Video Inputs – 1 x 12G‑SDI Micro BNC
SDI Video Outputs – 1 x 12G‑SDI Micro BNC
SDI Rates – 3G, 6G, 12G.
HDMI 2.0 Video Outputs – 1
HDMI Video Outputs – 1 x HDMI Type A output.
HDMI output is always HD, up to 1080p60.
Analog Audio Input – 1 x 3.5mm Stereo Input. Can also be used for Timecode input.
Reference Inputs – Program SDI Input on camera.
SDI Audio Output – 2 channels of program audio embedded in 3G/6G/12G-SDI.
HDMI Audio Outputs – 2 channels 48 kHz and 24‑bit.
Remote Control – Remote camera control over SDI, HDMI or USB Ethernet with suitable adapter.
Computer Interface – 1 x USB Type‑C 3.1 Gen 1 (up to 5Gb/s) expansion ports for external recording and focus / zoom demand connection. Software updates using USB‑C Port.
Microphone – Integrated stereo microphone.
Built in Speaker – None
SD Video Standards – None
HD Video Standards – 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60
Ultra HD Video Standards – 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60
SDI Compliance – SMPTE 292M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1 and SMPTE 2082‑10.
SDI Audio Sampling – Television standard sample rate of 48 kHz and 24‑bit.
